Size | Ply Rating |
Load Index | Speed Symbols |
Standard Rim |
Max Load and Inflated Pressure | Overall Diameter (mm) |
Section Width (mm) |
Tread Depth (mm) | Operation Norm |
|||
Dual | Single | |||||||||||
kg | kPa | kg | kPa | |||||||||
10.00R20 | 18 | 149/146 | K | 7.50 | 3000 | 930 | 3250 | 930 | 1054 | 278 | 21.00 | GB |
11.00R20 | 16 | 150/147 | K | 8.00 | 3075 | 830 | 3350 | 830 | 1085 | 293 | 210.00 | GB |
11.00R20 | 18 | 152/149 | K | 8.00 | 3250 | 930 | 3550 | 930 | 1085 | 293 | 21.00 | GB |
12.00R20 | 18 | 154/151 | K | 8.50 | 3450 | 820 | 3750 | 830 | 1125 | 315 | 21.50 | TRA |
12.00R20 | 20 | 156/153 | K | 8.50 | 3650 | 9C0 | 4000 | 900 | 1125 | 315 | 21.50 | GB |
11R22.5 | 14 | 144/142 | L | 8.25 | 2650 | 720 | 2800 | 720 | 1065 | 279 | 22.00 | TRA |
11R22.5 | 16 | 146/143 | L | 8.25 | 2725 | 830 | 3000 | 830 | 1065 | 279 | 22.00 | TRA |
11R22.5 | 16 | 148/145 | L | 8.25 | 2900 | 850 | 3150 | 850 | 1065 | 279 | 22.00 | ETRTO |
12R22.5 | 16 | 152/148 | L | 9.00 | 3150 | 850 | 3550 | 850 | 1084 | 300 | 23.00 | ETRTO |
12R22.5 | 18 | 152/149 | M | 9.00 | 3250 | 930 | 3550 | 930 | 1085 | 300 | 23.00 | GB |
295/80822.5 | 16 | 152/148 | L | 9.00 | 3150 | 850 | 3550 | 850 | 1044 | 298 | 23.00 | ETRTO |
295/80R22.5 | 18 | 152/149 | L | 9.00 | 3250 | 900 | 3550 | 900 | 1044 | 298 | 23.00 | GB |
315/80R22.5 | 18 | 154/150 | L | 9.00 | 3350 | 825 | 3750 | 825 | 1076 | 312 | 23.00 | ETRTO |
315/80R22.5 | 20 | 156/150 | L | 9.00 | 3350 | 850 | 4000 | 850 | 1076 | 312 | 23.00 | ETRTO |
285/70R19.5 | 16 | 140/137 | M | 8.25 | 2300 | 725 | 2500 | 725 | 895 | 283 | 19.00 | ETRTO |
285/70R19.5 | 18 | 146/144 | M | 8.25 | 2800 | 900 | 3000 | 900 | 895 | 283 | 19.00 | ETRTO |
285/70R19.5 | 18 | 150/148 | J | 8.25 | 3150 | 900 | 3350 | 900 | 895 | 282 | 19.00 | ETRTO |
315/70R22.5 | 16 | 154/150 (152/148) |
L(M) | 9.00 | 3350 | 900 | 3750 | 900 | 1014 | 312 | 23.00 | ETRTO |
315/70R22.5 | 18 | 156/150 (154/150) |
L(M) | 9.00 | 3350 | 900 | 4000 | 900 | 1014 | 312 | 23.00 | ETRTO |
315/60822.5 | 16 | 152/148 | L | 9.75 | 3150 | 900 | 3550 | 900 | 950 | 313 | 23.00 | ETRTO |
